W11S 3 Roller Plate Rolling Machine

Configurations

plate rolling machine

SPS ® W11S Plate Rolling Machine



Hydraulic type three-roller plate rolling machine can roll the plate into cylindrical, arc and conical shape.

• This type of plate rolling machine has the function of pre-bending the plate ends, and the remaining straight edge of the pre-bend is ≤ 2.5 times the plate thickness.

• Large-size LCD touch screen digital display, human-machine dialogue control interface, efficient and intuitive operation.

-

Model

Pressure of Top Roller

T

Max Bending Thickness

Mm

Pre-Bending Thickness

Mm

Max Bending Length

Mm

Plate Yield Limit

Mpa

Top Roller Diamter

Mm

Bottom Roller Diameter

Mm

Central Distance

Mm

Main Motor

Kw

W11S-4x2500 25 4 3.5 2500 245 200 125 160 4
W11S-6x2500 30 6 5 2500 245 210 125 160 4
W11S-8x2000 37 8 6.5 2000 245 210 135 180 4
W11S-8x2500 37 8 6.5 2500 245 235 135 180 5.5
W11S-10x2000 37 10 8 2000 245 235 135 180 5.5
W11S-10x2500 55 10 8 2500 245 250 145 200 7.5
W11S-12x2000 65 12 10 2000 245 250 145 200 7.5
W11S-12x2500 75 12 10 2500 245 265 145 200 7.5
W11S-12x3000 75 12 10 3000 245 290 150 245 11
W11S-16x2000 75 16 13 2000 245 265 150 245 7.5
W11S-16x2500 100 25 13 2500 245 300 165 270 15
W11S-16x3000 130 16 13 3000 245 330 180 300 15
W11S-20x2000 100 20 16 2000 245 300 165 270 15
W11S-20x2500 130 20 16 2500 245 330 180 300 15
W11S-20x3000 160 20 16 3000 245 380 200 330 18.5
W11S-20x4000 230 20 28 4000 245 400 235 380 30
W11S-25x2500 190 25 20 2500 245 380 220 360 22
W11S-25x3000 230 25 20 3000 245 410 235 380 30
W11S-25x4000 270 25 20 4000 245 490 250 400 30
W11S-30x2500 230 30 25 2500 245 410 235 380 30
W11S-30x3000 270 30 25 3000 245 450 250 400 30
W11S-30x4000 380 30 25 4000 245 550 275 460 45
W11S-35x2500 320 35 28 2500 245 450 250 400 30
W11S-35x3000 380 35 28 3000 245 510 275 460 45
W11S-40x2500 380 40 32 2500 245 500 275 460 45
W11S-40x3000 430 40 32 3000 245 540 290 500 55
W11S-40x4000 540 40 32 4000 245 630 340 610 55
W11S-45x3000 540 45 36 3000 245 590 340 610 55
W11S-50x2500 430 50 40 2500 245 580 290 500 55
W11S-50x3000 540 50 40 3000 245 600 340 610 55
W11S-50x4000 690 50 40 4000 245 700 380 700 75
W11S-55x3000 610 55 45 3000 245 620 360 650 75
W11S-55x4000 850 55 45 4000 245 750 420 780 90
W11S-60x3000 690 60 50 3000 245 650 380 700 75
W11S-60x4000 930 60 50 4000 245 780 440 820 90
W11S-70x3000 850 70 56 3000 245 710 420 780 75
W11S-70x4000 1150 70 56 4000 245 840 480 920 110
W11S-75x3000 930 75 60 3000 245 740 440 820 90
W11S-80x3000 1050 80 65 3000 245 770 460 880 90
W11S-90x3000 1150 90 705 3000 245 820 480 920 110
W11S-100x3000 1350 100 80 3000 245 860 480 920 110
W11S-110x4000 1800 100 90 4000 245 950 600 1120 132
W11S-120x3000 1800 120 100 3000 245 920 580 1120 132
W11S-120x4000 2300 120 100 4000 245 990 640 1280 275
